Items |
TD15.625-15.625 |
TD15.625-31.25 |
TD31.25-31.25 |
Customized |
||
|
Pixel pitch |
W15.62mm*H15.62mm |
W15.62mm*H31.25mm |
W31.25mm*H31.25mm |
W31.25mm*H31.25mm |
||
|
LED type |
DIP346(1R1G1B) |
DIP346(1R1G1B) |
DIP346(1R1G1B) |
DIP346(customized) |
||
|
Cabinet Size(mm) |
W1000*H500*D70.5 |
|||||
|
Cabinet Resolution |
64*32 |
64*16 |
32*16 |
-- |
||
|
Cabinet Weight(kg) |
9 |
7.5 |
6.5 |
-- |
||
|
Scan(s) |
steady state |
steady state |
steady state |
-- |
||
|
Grey Scale(Bit) |
12 |
|||||
|
IP Rating |
IP65 |
|||||
|
Refresh rate (Hz) |
1920 |
|||||
|
Brightness(CD/㎡ ) |
10000 |
7500 |
4500 |
-- |
||
|
Peak Power(W/SQM) |
800 |
600 |
400 |
-- |
||
|
Average power(W/SQM) |
250 |
200 |
150 |
-- |
||
|
IP rate |
IP65 |
|||||
|
Viewing distance(M) |
＞16M |
＞16M |
＞31M |
-- |
||
